Vertiv Liebert APS 5kVA Modular UPS | Scalable to 15kVA N+1 | 120/208V Split Phase
The Vertiv Liebert APS AS5A0NCVGNNXLKB is a high-performance, modular online double conversion UPS designed for mission-critical applications. Delivering 5kVA capacity and scalable to 15kVA N+1, this split-phase (120/208V) UPS provides up to 15 minutes of full-load runtime, ideal for server rooms and enterprise IT systems.
Equipped with factory-installed SNMP/Webcard (IS-UNITY-DP), it enables seamless remote management via free Power Insight software. Its rack/tower convertible form factor, hot-swappable FlexPower and battery modules, and transformer-based design offer unmatched flexibility and uptime. Energy efficiency reaches up to 92%, reducing TCO and supporting green initiatives. Fully compliant with global safety and environmental standards, this unit is new and factory fresh, backed by a 2-year limited warranty.
| Specification | Details |
|---|---|
| Manufacturer | Vertiv |
| Brand | Liebert |
| Product Line | APS |
| Model Number | AS5A0NCVGNNXLKB |
| UPS Topology | Online Double Conversion |
| Scalability | 5kVA to 15kVA N+1 |
| Output Voltage | 120/208V Split Phase |
| Input Voltage Range | 120V – 280V AC |
| Input/Output Frequency | 70 Hz Input / 60 Hz Output |
| Full Load Runtime | 15 Minutes |
| Half Load Runtime | 40 Minutes |
| Form Factor | Rack/Tower Convertible |
| Plug/Connector Type | Hard Wire 4-wire (L-L-N-G) |
| Communication Interfaces | USB, Serial, EPO Port |
| Pre-Installed Card | SNMP/Webcard (IS-UNITY-DP) |
| Free Software | Trellis™ Power Insight |
| Battery Type | Valve-Regulated Lead Acid |
| Battery Hot Swappable | Yes |
| Efficiency | Up to 92% |
| Max Charge Current | 10A w/ Charger Module |
| Nominal Battery Voltage | 144VDC |
| Mounting Options | Rack or Tower, with casters |
| Humidity/Altitude | 0–95% RH, up to 3000m @ 25°C |
| Dimensions (H x W x D) | 42" x 17" x 32" |
| Product Condition | New and Factory Fresh |
| Shipping Weight | 1 lb. (as stated) |
| Certifications | UL 1778, CSA, FCC, IEC/EN/AS 62040 |
| Environmental Compliance | RoHS, WEEE, REACH |
| Warranty |
2-Year Limited Warranty |
