Eaton Power-Sure 800 T800F-05000 Single-Phase Transformer, 5 kVA, 120/208/240V
by Eaton
The Eaton T800F-05000 is a heavy-duty single-phase transformer from the Power-Sure 800 series, designed for efficient and reliable power conditioning in demanding environments. Delivering 5 kVA (5 kW) of power with an output of 120/208/240V, this floor-mounted transformer ensures stable and clean power to your equipment. It features hardwired output, high efficiency (92% at full load), and operates within a wide temperature range of -20°C to 40°C. Ideal for commercial and industrial settings, the unit is backed by a 2-year warranty and certified to UL 1012, UL 544, and cUL listed standards.
| Specification | Details |
|---|---|
| Product Name | Eaton Power-Sure 800 |
| Catalog Number | T800F-05000 |
| UPC | 743172022547 |
| Type | Transformer (Power Conditioner) |
| Topology | Line Conditioner |
| Phase | Single-phase |
| Power Rating | 5 kVA / 5 kW |
| Output Voltage | 120/208/240V |
| Output Connection | Hardwired |
| Mounting Type | Floor |
| Efficiency | Approximately 92% at full load |
| Operating Temperature | -20°C to 40°C |
| Product Dimensions (LxWxH) | 20 in x 23 in x 28.5 in |
| Weight | 407 lb |
| Certifications | UL 1012, UL 544, cUL Listed |
| Warranty | 2 years |
