Eaton ATS Rack PDU, 1U, (2) L6-30P, 4.99kW, 208-240V, 24A, (6) C13 & (3) C19 Outlets, 9 ft Cord
by Eaton
Ensure high availability and seamless power transition with the Eaton T2235-3209 ATS Rack PDU. Designed for critical IT infrastructure, this 1U Automatic Transfer Switch (ATS) PDU features dual input cords (L6-30P) that provide reliable source redundancy. With a 4.99 kW power rating, 24A capacity, and a 208–240V single-phase input, it is ideal for maintaining uptime in enterprise environments.
Equipped with six C13 and three C19 outlets, the unit supports a range of devices, from networking gear to high-draw servers. Its 1U horizontal form factor allows for efficient use of rack space, and the 9 ft input cord provides flexible installation. TAA compliance and UL listing ensure adherence to high-quality standards.
| Category | Details |
|---|---|
| Product Name | Eaton ATS PDU |
| Catalog Number | T2235-3209 |
| UPC | 786680223846 |
| Series | eATS |
| Form Factor | 1U, Horizontal |
| Mounting | Rackmount |
| Input Voltage | 208-240V, Single-phase |
| Input Frequency | 50/60 Hz |
| Input Connections | (2) L6-30P |
| Output Receptacles | (6) C13, (3) C19 |
| Circuit Breakers | (3) 2P 15A |
| Wattage | 4.99 kW Max |
| Amperage Rating | 24A |
| Cord Length | 9 ft |
| Color | Black |
| Operating Temperature | 0° to 60°C (32° to 140°F) |
| Dimensions (WxHxD) | 25 x 10 x 15 in |
| Weight | 20 lb |
| Certifications | UL Listed, TAA Compliant |
| Warranty | 3-Year Limited Warranty |
| Outlet Control | No |
