Vertiv Geist NS30061L 24-Outlets Switched PDU, 17.2kW, 60A, 0U Vertical, Hardwired
by Vertiv
The Vertiv Geist NS30061L is a 24-outlet switched PDU that delivers advanced power monitoring and remote outlet control. Ideal for high-density rack environments, this unit supports real-time monitoring down to the phase and circuit level. Its Visible Light Communication (VLC) LED display allows optical data transmission to mobile devices via the Geist Mobile App. Equipped with hot-swappable upgradeability through an Interchangeable Monitoring Device (IMD), the NS30061L ensures future-proof flexibility and reliability. It features 18 IEC C13 and 6 IEC C19 locking outlets, vertical 0U rack mounting, and robust environmental support with 60A input and 17.2kW power capacity.
| Category | Details |
|---|---|
| Manufacturer | Vertiv |
| Brand Name | Geist |
| Model | MNS3EGW1-24PH68-6HW15A9BXX-S-A |
| Part Number | NS30061L |
| PDU Type | Switched |
| Phase | Three Phase |
| Input Voltage | 230 V AC (Range: 200–240 V AC) |
| Output Voltage | 208 V AC |
| Power Rating | 17.20 kW |
| Input Current | 60 A |
| Plug Type | Hardwired |
| Outlets | 18 × Locking IEC 60320 C13, 6 × Locking IEC 60320 C19 |
| Protection | Overcurrent Protection |
| Mounting Orientation | Vertical |
| Rack Height | 0U |
| Mount Type | Rack-mountable |
| Dimensions (W × D × L) | 2.3" × 2.6" × 72" |
| Network Interface | RJ-45 |
| Management Protocols | DHCP, HTTP/HTTPS, SNMP (v1/v2c/v3), SSH, Syslog, SMTP, LDAP, NTP, RSTP, IPv4/IPv6 |
| Remote Outlet Switching | Yes |
| Environmentally Friendly | Yes |
| Country of Origin | United States |
| Package Includes | PDU Unit, Vertical Mounting Bracket Kit |
| Warranty | 5-Year Limited |
| Shipping Weight | 22 lbs |
| Product Condition | New and Factory Fresh |
