Vertiv Geist VP6U20A1 Monitored rPDU, 24 Outlets, 16/20A, C20 Plug
by Vertiv
The Vertiv Geist VP6U20A1 is a vertical, monitored outlet-level rPDU designed to deliver reliable and intelligent power distribution to critical IT equipment. With 24 locking outlets (21 × IEC C13 and 3 × IEC C19), environmental monitoring support, and advanced power usage analytics via remote access, this unit helps ensure uptime, prevent thermal issues, and optimize energy usage. Daisy-chain up to 50 rPDUs on one IP address, with hot-swappable monitoring modules for future scalability.
| Specification | Details |
|---|---|
| Model | VP6U20A1 |
| Part Number | MUR5MGB0-24PK37-2C20A9A00-S |
| Form Factor | Vertical (Zero U) |
| Dimensions (L × W × D) | 66.25 in × 2 in × 2.6 in (1683 mm × 51 mm × 66 mm) |
| Mounting | Toolless Vertical; Bracket Kit Included |
| Power Input | IEC C20 Inlet |
| Input Voltage | 100-240V, 50/60Hz |
| Current Rating | 16A or 20A |
| Power Capacity | 1.9kW (120V), 3.3kW (208V), 3.6kW (230V) |
| Receptacles | 21 × Locking IEC C13, 3 × Locking IEC C19 |
| Monitoring | Input & Outlet Level (kWh, W, VA, PF, V, A) |
| Display | Local LCD, auto-oriented |
| Network Connectivity | Dual Gigabit Ethernet |
| Protocols Supported | SNMP v1/v2c/v3, HTTPS, SSH, Modbus TCP, JSON API, etc. |
| Remote Sensors Supported | 1 × RJ Port (up to 16 sensors) |
| Environmental Monitoring | Yes (with optional sensors) |
| Certifications | UL/cUL 62368-1, CE, UKCA, RoHS, FCC Part 15 Class A, RCM, China RoHS |
| Operating Temperature | Max 60°C (140°F) |
| Chassis Color | Black Powder Coat |
| Warranty | 5 Years (if registered within 120 days); otherwise 3 Years |
| Weight (Shipped) | 18 lbs (8.16 kg) |
