Vertiv VP6UV0A3 PowerIT rPDU, 22.0kW, Monitored Outlet, 24 x C13/C19, Vertical
by Vertiv
The Vertiv VP6UV0A3 PowerIT Rack PDU delivers reliable and intelligent power distribution to critical IT infrastructure. With outlet-level EC monitoring, this vertical 0U rPDU provides real-time visibility into power usage and environmental conditions via remote network access. It supports daisy chaining of up to 50 devices with advanced Ethernet connectivity and integrates seamlessly with Vertiv's monitoring ecosystem. The VP6UV0A3 is built for high-density environments, combining a universal input with 24 combination C13/C19 outlets and a high-visibility local LCD display.
| Specification | Details |
|---|---|
| Part Number | VP6UV0A3 |
| Power Configuration | Variable, up to 22.0kW |
| Input Type | Universal Inlet |
| Input Power Options | 63A 1-Ph 240V / 48A 3-Ph Delta 240V / 32A 3-Ph WYE 240/415V |
| Form Factor | Vertical, 0U |
| Dimensions (L x W x D) | 66.25in x 2in x 2.6in (1683mm x 51mm x 66mm) |
| Receptacles | 24 x Combination C13/C19 |
| Circuit Breakers | (6) x 16A Double Pole Magnetic (10kAIC Rated) |
| Circuit ID Color Coding | Orange, Green, Blue, Light Orange, Light Green, Light Blue |
| Monitoring Type | Monitored Outlet Level EC |
| Local Display | LCD Touchscreen, Auto-Oriented |
| Network Connectivity | Dual 10/100/1000 Mbps Ethernet, Daisy Chain (up to 50 devices) |
| Protocols Supported | SNMP (v1/2c/3), HTTPS, RADIUS, Modbus TCP, Syslog, TACACS+, etc. |
| Environmental Sensors Support | Yes (1 RJ connection, up to 16 sensors) |
| Operating Temp. | Up to 60°C (140°F) |
| Finish | Heavy-duty steel, black powder coat |
| Mounting Hardware | Included (4689 UPDU bracket, tool-less) |
| Certifications | UL & c-UL 62368-1, CE, UKCA, FCC Part 15 Class A, RoHS, China RoHS |
| Warranty | 5-year (with registration), 3-year otherwise |
| Country of Origin | USA, TAA and BAA COTS compliant |
| Weight (Shipping) | 27 lbs (12.25 kg) |
