Vertiv VP6N30AP Monitored Outlet-Level rPDU, 30A, 208V, 4.9kW, Vertical
by Vertiv
The Vertiv VP6N30AP PowerIT™ rPDU delivers reliable, high-density power distribution with advanced outlet-level EC monitoring. This vertical 66" 30A rPDU supports real-time input and outlet-level power monitoring, environmental sensor integration, and daisy-chain Ethernet connectivity. Ideal for high-availability IT environments, the VP6N30AP features 24 combination C13/C19 outlets, a 10ft L6-30P power cord, fault-tolerant operation, and an intuitive local display. Designed for flexibility, performance, and future upgrades.
| Specification | Details |
|---|---|
| Part Number | VP6N30AP |
| Power Rating | 30A, 208V, 4.9kW |
| Form Factor | Vertical (Zero U), 66.25in x 2in x 2.6in |
| Mounting | Vertical mount with toolless hardware (7938 bracket) |
| Receptacles | 24x Combination C13/C19 (12 per breaker pair) |
| Plug Type | NEMA L6-30P (10ft / 3m cord) |
| Monitoring | Input & outlet-level power, circuit/breaker current |
| Display | Local high-visibility LCD touchscreen |
| Network Connectivity | Dual Gigabit Ethernet, Daisy-chain capable (up to 50) |
| Protocols Supported | SNMP v1/v2c/v3, HTTPS, Modbus TCP, RADIUS, etc. |
| Sensors Supported | Up to 16 via RJ port |
| Breaker Protection | (2) 20A Double Pole Magnetic Breakers (5kAIC Rated) |
| Chassis Finish | Heavy steel, black powder coat |
| Certifications | UL & c-UL 62368-1, RoHS, FCC Part 15 Class A |
| Compliance | TAA & Buy American Act (BAA) COTS Compliant |
| Country of Origin | USA |
| Operating Temperature | Up to 60°C / 140°F |
| Warranty | 5 years (with registration within 120 days) |
| Weight | 20 lbs (9.07 kg) |
