Vertiv VP7N30AR Switched rPDU, 30A 208V Delta, 36 Outlets, C13/C19, L15-30P
by Vertiv
The Vertiv VP7N30AR is a high-performance Switched Rack PDU (rPDU) designed for modern data centers requiring advanced power control and visibility. Offering individual outlet switching and detailed input/output monitoring, this vertical PDU supports critical IT infrastructure with 30A, 208V Delta input and a total power capacity of 8.6kW. It features 36 combination C13/C19 outlets, a 10-ft L15-30P twist-lock plug, environmental sensor support, and advanced remote management over dual Ethernet. Built with fault-tolerant daisy-chaining, local LCD display, and robust metal housing, the VP7N30AR ensures power reliability, monitoring, and control at the outlet level.
| Specification | Details |
|---|---|
| Part Number | VP7N30AR |
| Input Voltage / Current | 208V Delta / 30A (3-Phase) |
| Power Capacity | 8.6kW |
| Frequency | 50/60Hz |
| Input Plug Type | NEMA L15-30P |
| Receptacles | 36 x Combination C13/C19 |
| Outlet Configuration | Banks of 6, Alternating Phase, Color-Coded (Orange, Green, Blue) |
| Outlet Switching | Yes – Individual Outlet with Sequencing Options |
| Monitoring Capabilities | Input, Outlet, Circuit/Breaker (kWh, W, VA, PF, A, V) |
| Network Connectivity | Dual Ethernet (10/100/1000 Mbps), Daisy Chain (up to 40 rPDUs) |
| Supported Protocols | SNMP (v1/2c/3), HTTPS, SSH, RADIUS, TACACS+, Modbus TCP, Syslog, etc. |
| Local Display | LCD Touchscreen, Auto Oriented |
| Remote Sensor Ports | 1 x RJ Port (supports up to 16 sensors) |
| Power Cord Length | 10 ft / 3m |
| Mounting | Vertical (Zero U), Toolless Brackets Included (61.25" and 64.75" spacing) |
| Chassis Dimensions (HxWxD) | 72 x 2 x 2.6 in / 1829 x 51 x 66 mm |
| Weight | 22 lbs / 9.98 kg |
| Finish | Heavy Steel, Black Powder Coat |
| Certifications | UL 62368-1, RoHS, FCC Part 15 Class A, TAA and BAA Compliant |
| Warranty | 5-Year Limited (with registration) |
