Vertiv VP5UU0A2 Switched rPDU, 11.0kW, (24) C13/C19, Universal Inlet
by Vertiv
The Vertiv VP5UU0A2 is a high-performance Switched rack Power Distribution Unit (rPDU) engineered for data center and critical IT infrastructure. Designed with unit-level input power monitoring and remote individual outlet switching, it delivers superior power control and visibility. This 72-inch vertical unit features 24 combination C13/C19 outlets, a universal inlet, and a durable black powder coat finish. Environmental monitoring, daisy chaining up to 50 devices, and a dual Ethernet interface make it an advanced choice for scalable, intelligent power management.
| Feature | Specification |
|---|---|
| Model Number | VP5UU0A2 |
| Product Type | Switched rPDU, Unit Level Monitoring |
| Power Capacity | Up to 11.0kW (varies by input config) |
| Input Power | Universal Inlet |
| Receptacles | (24) Combination C13/C19 |
| Voltage | Up to 240/415V, depending on phase |
| Current Rating | Up to 48A Single Phase, 24A Delta, 16A WYE |
| Monitoring | Input monitoring, Circuit monitoring, Outlet switching |
| Environmental Monitoring | Via optional remote sensors |
| Daisy Chaining | Up to 50 units, fault-tolerant with RSTP |
| Networking | Dual Ethernet (10/100/1000Mbps), SNMP, HTTP/HTTPS, etc. |
| Display | Auto-orienting touchscreen LCD, 24 LEDs |
| Dimensions (HxWxD) | 72in x 2in x 2.6in (1829mm x 51mm x 66mm) |
| Weight | 27 lbs (12.25 kg) |
| Mounting | Vertical (Zero U), Toolless hardware included |
| Material & Finish | Heavy-duty steel, Black powder coat |
| Compliance | UL, c-UL, CE, RoHS, FCC Part 15 Class A, TAA, BAA Compliant |
| Warranty | 5-Year (if registered within 120 days) |
