Vertiv VP5U20A2 Switched rPDU, 20A, 120–240V, (24) IEC Outlets, Vertical
by Vertiv
The Vertiv VP5U20A2 PowerIT Switched rPDU delivers reliable, intelligent power distribution with advanced monitoring and remote outlet-level switching. Ideal for data centers and network closets, this vertical 66-inch unit supports up to 3.6kW with 24 locking IEC outlets (18 C13, 6 C19), a C20 inlet, and real-time input power and environmental monitoring via optional sensors. Designed for fault-tolerant daisy chaining, up to 50 devices can be managed under a single IP. Featuring local LCD display, secure remote access, and robust steel construction, it’s built for mission-critical uptime.
| Specification | Details |
|---|---|
| Model | VP5U20A2 |
| Type | Switched rPDU, Unit Level Monitoring |
| Input Voltage | 100–240V |
| Current Rating | 16A or 20A |
| Load Capacity | 1.9kW (120V), 3.3kW (208V), 3.6kW (230V) |
| Input Plug Type | IEC60320 C20 (Cord Sold Separately) |
| Outlet Configuration | (18) Locking IEC C13, (6) Locking IEC C19 |
| Mounting | Vertical, 66.25 in / 1683 mm (Zero U) |
| Display | Local LCD with auto-orientation |
| Networking | Dual 1GbE (DHCP, SNMPv3, HTTPS, RADIUS, SSH, etc.) |
| Environmental Monitoring | Optional remote sensors supported (up to 16) |
| Daisy Chain Capability | Up to 50 units on a single IP address |
| Material / Finish | Heavy Steel with Black Powder Coat |
| Certifications | UL, c-UL, CE, UKCA, FCC Part 15A, RoHS, RCM, China RoHS |
| Warranty | 5-Year Limited (if registered within 120 days) |
