Vertiv Geist VP5U20A0 Switched rPDU, 24xC13, 16A/20A, Vertical
by Vertiv
The Vertiv Geist VP5U20A0 is a switched rack PDU (rPDU) that delivers reliable power distribution and remote management for critical IT environments. Designed with 24 locking IEC C13 outlets, a high-visibility local display, and environmental monitoring capabilities, this unit supports input monitoring, outlet-level switching, and daisy-chaining up to 50 devices over a single IP. Ideal for high-density data centers and edge applications, the VP5U20A0 ensures uptime with advanced features such as fault-tolerant networking, remote reboots, and compatibility with multiple input voltages.
| Specification | Details |
|---|---|
| Model Number | VP5U20A0 |
| Form Factor | Vertical (Zero U) |
| Dimensions (LxWxD) | 66.25 in x 2 in x 2.6 in (1683 mm x 51 mm x 66 mm) |
| Power Capacity | 1.9kW (120V), 3.3kW (208V), 3.6kW (230V) |
| Voltage Range | 100–240V |
| Current Rating | 16A or 20A |
| Input Plug Type | IEC60320 C20 (cord sold separately) |
| Receptacles | 24 x Locking IEC C13 (U-Lock, 1 Circuit Orange ID) |
| Monitoring | Unit-level, input power monitoring, LCD local display |
| Switching | Individual outlet switching with delays and sequencing |
| Network Connectivity | Dual 10/100/1000Mbps Ethernet |
| Protocols Supported | SNMP, HTTP/S, SSH, Modbus TCP, RADIUS, Syslog, etc. |
| Environmental Monitoring | Optional sensors via RJ connection (up to 16 sensors) |
| Mounting | Vertical bracket kit included (61.25"/64.75" spacing) |
| Construction | Heavy steel with black powder coat finish |
| Temperature Rating | Max 60°C / 140°F |
| Certifications | UL, CE, UKCA, FCC, RoHS, RCM, China RoHS, etc. |
| Warranty | 5 years (if registered within 120 days); otherwise 3 years |
