Vertiv VP5N30AQ Switched rPDU, 30A, 8.6kW, Vertical, C13/C19, L21-30P
by Vertiv
The Vertiv VP5N30AQ is a high-performance switched rPDU designed for reliable power distribution and intelligent outlet-level control in data centers and IT environments. With unit-level monitoring, environmental sensor support, and remote switching capabilities, this vertical 30A, 120/208V WYE rPDU provides 8.6kW capacity through 36 combination C13/C19 outlets. Built with daisy-chainable Ethernet connectivity, an auto-oriented touchscreen display, and fault-tolerant design, it's ideal for efficient power management and uptime assurance.
| Specification | Details |
|---|---|
| Part Number | VP5N30AQ |
| Form Factor | Vertical, Zero U |
| Input Voltage | 120/208V WYE |
| Input Current | 30A, 3-Phase |
| Load Capacity | 8.6kW |
| Plug Type | NEMA L21-30P Twistlock |
| Receptacles | 36x Combination C13/C19 |
| Monitoring | Unit-Level + Circuit/Breaker + Environmental |
| Switching | Individual Outlet-Level Switching |
| Mounting | Vertical Bracket Kit Included |
| Display | LCD Touchscreen (Auto-Oriented) |
| Network Connectivity | Dual Ethernet (10/100/1000 Mbps) |
| Supported Protocols | SNMP (v1/v2c/v3), SSH, HTTP/S, Modbus TCP, etc. |
| Sensor Ports | 1 RJ sensor port (supports up to 16 sensors) |
| Power Cable Length | 10ft / 3m |
| Breaker Configuration | (3) 20A Double Pole Magnetic Breakers |
| Finish | Black Powder-Coated Steel |
| Dimensions (HxWxD) | 72 x 2 x 2.6 in / 1829 x 51 x 66 mm |
| Weight | 22 lbs (9.98 kg) |
| Compliance | UL 62368-1, RoHS, FCC Part 15 Class A, TAA |
| Warranty | 5 Years (if registered within 120 days) |
| Country of Origin | USA |
