Vertiv VP5N30AV Switched rPDU, 30A 208V, 4.9kW, 36x C13/C19, Vertical
by Vertiv
The Vertiv VP5N30AV is a high-performance Switched rack PDU (rPDU) designed for critical IT environments. It offers unit-level monitoring and individual outlet switching for enhanced power management and remote control. This 70-inch vertical unit supports up to 36 combination C13/C19 outlets, with a 10-foot L6-30P input plug, delivering 4.9kW at 208V. Ideal for modern data centers, it supports advanced network protocols, environmental monitoring via optional sensors, and daisy chaining for up to 50 devices.
| Feature | Details |
|---|---|
| Part Number | VP5N30AV |
| Form Factor | Vertical, Zero U (70in / 1778mm) |
| Input Voltage / Current | 208V, 30A |
| Power Capacity | 4.9kW |
| Input Plug Type | NEMA L6-30P Twistlock |
| Receptacle Type | 36x Combination C13/C19 |
| Monitoring | Unit level input & circuit monitoring, outlet switching |
| Breakers | (2) 20A Double Pole Magnetic Breakers (10kAIC) |
| Power Cord | 10ft (3m), 10/3 Gauge |
| Network Connectivity | Dual Ethernet (10/100/1000Mbps), Daisy Chain up to 50 |
| Protocols Supported | DHCP, SNMP (v1/v2c/v3), HTTPS, Modbus TCP, etc. |
| Environmental Monitoring | Via optional remote sensors (up to 16 supported) |
| Display | LCD Touchscreen, LED Indicators |
| Operating Temperature | Up to 60°C (140°F) |
| Certifications | UL & c-UL 62368-1, RoHS, FCC Part 15 Class A |
| Mounting Hardware | Toolless brackets included (multiple spacing options) |
| Finish | Heavy-duty black powder coat |
| Weight | 20 lbs (9.07 kg) |
| Warranty | 5-year limited (with registration), 3-year standard |
| Country of Origin | USA (TAA & BAA COTS Compliant) |
