Vertiv VRC100KIT Self-Contained Server Rack Cooling Unit – 3.5kW | 120V | 10U
The Vertiv VRC100KIT is a compact, self-contained cooling solution engineered for edge computing environments, small server rooms, and network closets. This unit delivers 3.5kW (12,000 BTU) of cooling capacity in a 10U rack-mounted form, making it ideal for IT spaces where floor space is limited.
Designed for energy efficiency, the VRC utilizes variable speed fans and a compressor to dynamically adapt to fluctuating IT loads, optimizing performance while reducing power consumption. Installation is streamlined with the inclusion of all required hardware, and SNMP/ModBus cards are pre-installed for full remote monitoring capabilities.
The VRC100KIT supports single-phase 120V 60Hz input, includes cable grooming, and is backed by Vertiv’s 2-year limited warranty.
| Specification | Details |
|---|---|
| Manufacturer | Vertiv |
| Part Number | VRC100KIT |
| Cooling Capacity | 3.5kW / 12,000 BTU |
| Voltage / Frequency | 120V AC / 60Hz |
| Form Factor | Rack-mountable (10U) |
| Plug Type | NEMA 5-20P |
| Cooling Type | Air Cooling |
| Power Consumption | 3500 W |
| Cooling Energy | 1266.1 kJ |
| Monitoring | SNMP Card, ModBus RTU |
| Mounting | Self-Mountable, Rack Compatible |
| Phase | Single Phase |
| Shipping Weight | 296 lbs |
| Condition | New and Factory Fresh |
| Warranty | Limited 2-Year (Extended Options Available) |
| Country of Origin | China |
