Eaton 93E 60KVA Internal Battery UPS, 208/220V 3-Phase, 9EB06GG05001003
The Eaton 93E 60KVA UPS (P/N: 9EB06GG05001003) delivers reliable, efficient backup power in a compact footprint ideal for IT, commercial, and industrial environments. Featuring online double-conversion topology, it supports up to 48KW of load with hardwired 208/220V three-phase input and output connections. The standard internal battery configuration provides up to 6.6 minutes of runtime at full load. Optional input/output transformers and accessories are available for flexible integration. Designed for ease of service and long-term value, the 93E is a scalable and efficient UPS solution with warranty extensions up to 3 years.
| General |
|
| SKU |
9EB06GG05001003 |
| Topology |
Online Double Conversion |
| Power Rating (KVA) |
60 KVA |
| Rated Load Capacity (KW) |
48 KW |
| Efficiency |
Up to 98% HE mode / 92% online |
| Standard Warranty |
12 months (with start-up) or 6 months (w/o start-up) |
| Optional Warranty |
Extension up to 3 years |
| Electrical Input |
|
| Input Voltage |
208 / 220V 3-phase |
| Input Connection |
Hardwired Terminal |
| Optional Input |
480V Input Transformer |
| Electrical Output |
|
| Output Voltage |
208 / 220V 3-phase |
| Output Connection |
Hardwired Terminal |
| Optional Output |
480V Output Transformer |
| Battery Backup |
|
| Runtime (Full Load) |
6.6 minutes |
| Runtime (Half Load) |
18 minutes |
| Battery Type |
Internal Standard Batteries |
| Extended Batteries |
Not supported |
| Physical Dimensions |
|
| Dimensions (H x W x D) |
73" x 23.6" x 31.5" |
| Weight |
1499 lbs |
| Recommended Accessories |
|
| Bypass Switch |
External (optional) |
| Communications |
Optional Network and Relay Cards |
